TDP-225 50mm (2") Brochure

TDP-225 2" 50mm Direct Thermal Label Printer
The TDP-225 printer is the first low cost compact 2” desktop printer to offer an optional LCD display to its customers. The LCD is used to present important information about print job status which brings a new level of ease of use to its customers. Other outstanding features include an inexpensive internal Ethernet adapter for easy integration into network systems, and an optional keyboard for printing labels in standalone or down-time situations.

With enhanced electronics, the TDP-225 offers a 200 MHz processor, standard memory of 4 MB FLASH, 8 MB SDRAM and a slot for a MicroSD memory expansion that increases FLASH storage up to 4 GB. The printer supports standard industry emulations right out of the box including Eltron® and Zebra® language support.
Model
Printing Method
Resolution
Max. Print Width
Max. Print Length
Max. Print Speed
TTP-225
Thermal Transfer
203 dpi
2.13"
90"
5 ips

Title: Title: Loading the media

"Click" Below to Watch Video's

Title: Title: Loading the ribbon
